Butt-Weld End Gate Valve

Application : Non Return Flow

Features / Benefit : OS & Y Construction Flexible Wedge Design (Choice of Solid  or Split Wedge Available) Full Port Design

Renewable Seat Rings & Integral Seat Rings Burnish Finish Stem for Low Operating Torque Pressure Seal Bonnet or Welded Bonnet on request for High Pressure

Ansi Class / Rating : 150#, 300#, 600#

Design Standard : API 600, BS 1414

Testing Standard : API 598, ISO 5208

F to F Standard : ASME B16.10

Size : 15 mm to 600 mm

Materials : Body : WCB, CF8, CF8M, Hast Alloy, Super Duplex, Alloy 20 , LCB etc Trim : 13 % Cr, Stellite etc

Ends : Flanged End, Butt Weld End

Operation : Manual, Pneumatic, Electric
