Industrial Ball Valves
High-integrity quarter-turn ball valves engineered for critical isolation in high-pressure, severe-temperature, and abrasive flow environments. Designed with precision spherical closures, low operating torque, and certified bubble-tight bidirectional shut-off across global energy and process pipelines.
Precision Flow Isolation, Low Operating Torque & Severe-Service Reliability
ENGIPRO SOLUTIONS LLP manufactures high-performance industrial ball valves engineered to provide positive bidirectional shut-off, low operating torque, and high flow capacity with minimal pressure drop. Built for high-reliability process isolation across chemical plants, oil refineries, gas pipelines, and power utilities, our ball valves are compliant with API 6D, ASME B16.34, API 608, and BS EN ISO 17292 standards.
Our product range encompasses both Floating Ball Valves (DN 15 to DN 250 / 1/2" to 10") where upstream pressure pushes the ball securely into the downstream seat ring, and heavy-duty Trunnion Mounted Ball Valves (DN 25 to DN 600 / 1" to 24") where the ball is anchored between rigid mechanical trunnions with spring-energized floating seats.
Depending on process media, operating temperatures, and slurry content, ENGIPRO ball valves are available in resilient soft-seated configurations (PTFE, RPTFE, PEEK) for bubble-tight isolation, and supersonic HVOF-coated metal-seated configurations (Tungsten Carbide, Chromium Carbide, Stellite 6) capable of handling abrasive particulates and severe heat up to 600°C.
Explore Ball Valve Models & Configurations
Click any valve model below to access in-depth engineering datasheets, dimensional drawings, and material selection guides.
API 6D • BUBBLE TIGHT
Soft Seated Ball Valves
Precision thermoplastic seats (Virgin PTFE, RPTFE, PEEK) delivering zero-leakage bubble-tight shut-off for process fluids, gas lines, and utilities.
SEVERE SERVICE • 600°C
Metal Seated Ball Valves
Hard-faced with supersonic HVOF tungsten carbide or Stellite for abrasive slurries, high temperatures up to 600°C, and erosive catalyst fines.
API 6D • DBB STANDARD
Trunnion Mounted Ball Valves
Mechanical trunnion-anchored ball absorbing pipeline loads, spring-loaded floating seats, and certified Double Block & Bleed (DBB) isolation.
Special Features & Engineering Construction
Engineered to satisfy API 6D, ASME B16.34, and ISO 14313 benchmarks for critical hydrocarbon transmission and process containment.
Double Block & Bleed
Simultaneous upstream and downstream sealing allows the central body cavity to be bled safely through a dedicated port to confirm seat isolation integrity.
Fire-Safe Certified
Designed and certified in accordance with API 607 and API 6FA. Features secondary metal-to-metal seating upon soft seal burnout during an emergency fire.
Blowout-Proof Stem
Internally assembled stem with integral retention collar prevents stem blowout under full system pressure, ensuring operator and plant safety.
Low Operating Torque
Self-lubricating PTFE/metal composite trunnion bearings absorb line pressure loads, enabling effortless actuation with smaller actuators and gear units.
Self-Relieving Cavity
Spring-loaded floating seats automatically relieve trapped liquid overpressure back into the pipeline when thermal expansion occurs in the closed cavity.
Emergency Sealant Ports
Fitted with standard stem and seat emergency sealant injection fittings with internal check valves to restore seal integrity during field upsets.
ISO 5211 Direct Mounting
Standard ISO 5211 mounting flange accommodates direct coupling to pneumatic scotch yoke, electric rotary, or hydraulic emergency actuators without brackets.
Anti-Static Grounding
Integral conductive spring-loaded plungers ensure electrical continuity between stem, ball, and valve body, eliminating static electrical discharge hazards.
Technical Specifications
Comparative design standards and operational parameters for ENGIPRO Industrial Ball Valves.
Operational Standards & Technical Parameters
| Design Standards | ASME B16.34, API 6D, API 608, BS EN ISO 17292 |
| Special Construction Features | One Piece, Two Piece, and Three-Piece Construction • Fire-Safe Design to API 607 / API 6FA • Anti-Blowout Stem • Double Block and Bleed (DBB) • Low Operating Torque • Cavity Self-Relief • Emergency Sealant Injection • ISO 5211 Actuator Mounting |
| End Flanges Compatibility | ASME B16.5, ASME B16.47 Series A & B, EN 1092-1 |
| Face to Face Dimensions | ASME B16.10, API 6D, BS EN 558 |
| Testing Standards | API 598, API 6D, ISO 5208 Rate A (100% Hydrostatic & Pneumatic) |
| End Connections | Raised Face Flange (RF) • Ring Type Joint (RTJ) • Butt Weld (BW) • Socket Weld (SW) • Screwed (NPT/BSPT) |
| Size Range |
Floating Type: DN 15 to DN 250 (1/2" to 10") Trunnion Mounted Type: DN 25 to DN 600 (1" to 24") |
| Pressure Rating | Class 150#, 300#, 600#, 800#, 900#, 1500#, 2500# (PN 10 to PN 420) |
| Operations | Manual Lever, Enclosed Worm Gearbox, Pneumatic Scotch Yoke, Electric Rotary Actuator, Electro-Hydraulic |
| Shutoff Rating | Zero Leakage for Soft Seated & Metal Seated as per API 6D / API 598 Rate A. |
Material Specification & Service Metallurgy
| TYPE OF SERVICE | VALVE SHELL MATERIAL | BALL, STEM & SEAT METALLURGY |
|---|---|---|
| General Service | Carbon Steel (ASTM A216 WCB / WCC, A105) | Carbon Steel (ENP Plated) / Virgin PTFE |
| Low Temperature (-46°C) | Low-Temp Steel (ASTM A352 LCC / LCB, LF2) | Stainless Steel 316 / Lip Seals & PEEK |
| Corrosive Chemical | Stainless Steel (ASTM A351 CF8M, F316 / F316L) | SS 316 / RPTFE / Devlon / PEEK |
| Sour Service (NACE MR0175) | Carbon Steel (A105 / WCB NACE compliant) | SS 316 / 17-4PH (NACE heat-treated) |
| High Temperature (up to 600°C) | Alloy Steel (A217 WC6, WC9) / CF8M | HVOF Tungsten Carbide / Stellite 6 |
| Offshore Marine & Seawater | Duplex (F51 / 2205) • Super Duplex (F53 / 2507) | Matching Duplex Alloys / Inconel 625 |
| Severe Acidic / Slurry | CRA (Inconel 625, Hastelloy C-276, Monel 400, Alloy 20) | CRA Alloys with Carbide Hardfacing |
Engineered for Critical Process Sectors
ENGIPRO ball valves deliver reliable bubble-tight shut-off across extreme temperature, pressure, and corrosive environments.
Cross-Country Oil & Gas Pipelines
Mainline sectionalizing, scraper pig launcher and receiver traps, and custody transfer stations requiring certified API 6D zero-leakage DBB.
Refinery & Petrochemical Processing
Hydrocarbon blending manifolds, catalytic cracking feed headers, distillation columns, and chemical feedstocks requiring NACE MR0175 sour service compliance.
Tank Farms & Terminal Storage
Bulk petroleum storage tank isolation, truck loading racks, rail terminal loading arms, and automated emergency shutdown valves (ESDVs).
Offshore Platforms & FPSO Ships
Subsea risers, topside gas compression modules, wellhead flowlines, and seawater injection pumps requiring corrosion-resistant CRA and Duplex alloys.
Natural Gas City Gate & Regulating
High-pressure gas pressure reduction skids, gas metering skids, compressor stations, and underground storage facilities operating at ASME Class 600/900.
Power Plants & Utilities
Heavy fuel oil supply piping, cooling water headers, auxiliary steam distribution, and hydrogen coolant circuits requiring zero-cavity leakage.
Need Custom Sized Ball Valves or Complete Actuation Skids?
Our technical engineers assist with breakaway torque sizing, MAST stem calculations, NACE compliance documentation, and full factory acceptance testing (FAT).
